Descripción
The MEI SCN6607N RS232 SC Advance Note Validator is a high-performance banknote validator featuring RS232 communication and a Stackerless (No Cashbox) configuration. Designed for high-volume cash handling applications that utilize external cash storage systems, it delivers exceptional note validation accuracy, advanced anti-fraud protection, and reliable long-term performance.
Key Features
- SC Advance™ Note Validator
- SCN6607N RS232 Model
- RS232 Communication Interface
- No Cashbox (Stackerless) Configuration
- Unit P1 Package
- High First-Pass Acceptance Rate
- Supports Over 140 Global Currencies
- Advanced Recognition Technology
- Barcode Ticket Acceptance
- Four-Way Note Acceptance
- Full Spectral Note Analysis
- Advanced Anti-Fraud Protection
- Sealed Note Path Design
- Anti-Skew Note Transport System
- Fast Note-To-Note Processing
- Durable Industrial Construction
- Low Maintenance Requirements
- Easy Firmware Updates
- Enhanced Machine Uptime
- OEM MEI Product
- Product Type: Note Validator
- Series: SC Advance™
- Model: SCN6607N RS232
- Configuration: SCN66
- Communication Interface: RS232
- Cashbox: None (Stackerless Version)
- Package Type: P1
- Acceptance Rate: 98% Or Greater
- Currency Support: Over 140 Currencies
- Note Acceptance: Four-Way Acceptance
- Note Width: 62 mm – 83 mm
- Note Length: 120 mm – 166 mm
- Escrow: One Note Or One Barcode Coupon
- Transaction Speed: Approximately 2.3 Seconds To Stack
- Operating Temperature: 0°C To 60°C
- Storage Temperature: -30°C To 70°C
- Humidity: 5% To 95% Non-Condensing
- Power Input: 12V – 28VDC
- Standby Power Consumption: 10 Watts
- Accepting Power Consumption: 30 Watts
- Stacking Power Consumption: 70 Watts
Technical Specifications
| Brand | Crane MEI |
| MPN | 252003154P1 |
| Voltage | 12V – 28VDC |
| Condition | New |
