Descripción
The WEL-RM017 is a 117V AC wiring harness cable designed to connect an AMP 172340-1 plug to a HORN-30 connector. Based on the wiring diagram, this harness is configured for 5V Enable interface applications and is used for power and data communication.
This harness is intended for compatible bill acceptor and machine interface setups requiring 115VAC hot, 115VAC neutral, earth ground, I-Enable-L, I-Enable-H, ground, and credit relay connections. It is a suitable replacement or service harness where the correct connector type and pinout are needed for AC-powered equipment.
Key Features
- Part Number: WEL-RM017
- Connector 1: AMP 172340-1
- Connector 2: HORN-30
- Operating Voltage: 117V AC
- Interface Type: 5V Enable
- Usage: Power & Data Communication
- Functions Supported: AC power, enable signals, ground, and credit relay connections
- Application: Replacement wiring harness for compatible AC-powered bill acceptor systems
Pin Functions
This harness wiring includes connections for the following signal and power assignments:
- 115VAC Hot (Power In)
- 115VAC Neutral (Power In)
- Earth Ground
- Ground (GND)
- I-Enable-L
- I-Enable-H
- Credit Relay N.O.
- Credit Relay COM
- Neutral Inhibit
Please verify your machine’s connector type, interface type, voltage requirements, and pinout before ordering to ensure compatibility.
Especificaciones técnicas
| Brand | ICT |
| Voltage | 110v |
| Condition | New |
