Description
The ICT V6E-33F0M-USD4-T# Bill Validator (V6E Series) is engineered for high-performance bill validation in vending and amusement machines, delivering reliable operation and advanced security.
Operating on 24V DC power, this validator supports the MDB interface, ensuring compatibility with modern vending systems. It provides a high acceptance rate of 96% or greater and processes transactions in approximately 3 seconds per bill, offering fast and efficient performance.
This model includes a 300-bill stacker capacity, making it ideal for medium-volume environments. The fitted bezel design ensures secure installation and seamless integration into machine panels.
Built for indoor use, the V6E validator offers durability, accuracy, and easy maintenance for operators.
Key Features
- High acceptance rate of 96% or higher
- Fast transaction speed (~3 seconds per bill)
- Accepts U.S. banknotes: $1, $5, $10, $20
- Four-way bill insertion
- Auto-calibration for improved accuracy
- Power Supply: 24V / 34V DC (20V–42.5V DC range)
- Bill Width Accepted: 60–67 mm
- Operating Temperature: 0°C to 55°C
- Storage Temperature: -30°C to 70°C
- Humidity: 30%–85% RH (non-condensing)
- Installation: Indoor
Technical Specifications
| Brand | ICT |
| Voltage | 34v |
| Supported Protocols | MDB |
| Stacker Capacity | 300 Bills |
| Bezel Type | Fitted |
| Denomination Acceptance | $1-$20 |
| Condition | New |
