Description
ICT WEL-RU1180 Cable
WEL-RU1180 USB Interface Specifications
| Interface | Used Voltage | Usage |
|---|---|---|
| USB for ICT Protocol | 5V DC | *Data Comm. |
WEL-RU1180 (Optional)
USB Connector Types:
- USB-A TYPE
- USB-B TYPE
USB Pin Assignments
| Pin | Color | Function |
|---|---|---|
| PN 1 | Red | VCC |
| PN 2 | White | D- |
| PN 3 | Green | D+ |
| PN 4 | Black | GND |
Technical Specifications
| Brand | ICT |
