Description
The MEI BNR411 S Chassis CB600+1RE+1LO is a modular banknote recycler chassis assembly from the BNR Advance series. This configuration includes a CB600 cashbox, one recycler module, and one loader cassette, providing secure cash management, advanced note validation, and reliable banknote recycling performance.
Key Features
- Chassis Configuration
- CB600 Cashbox Included
- 1 Recycler Module Included
- 1 Loader Cassette Included
- BNR Advance Series
- Banknote Recycler Chassis Assembly
- Supports Up To 6 Recycled Denominations
- Optical Validation Sensors
- USB Communication Interface
- Remote Firmware Updates
- Remote Note Set Updates
- High Acceptance Accuracy
- Secure Cash Management
- Modular Architecture
- Closed-Loop Cash Recycling
- Genuine MEI Product
- Model: BNR411 S
- Product Type: Chassis Assembly
- Cashbox: CB600
- Recycler Modules: 1RE
- Loader Cassette: 1LO
- Series: BNR Advance
- Dimensions (Closed): 604 mm × 165 mm × 275 mm
- Dimensions (Open): 604 mm × 165 mm × 336 mm
- Note Validation Range: 60–83 mm Width, 120–190 mm Length
- Interface Supported: USB
- Denominations Recycled: Up To 6
- Note Memory Capacity: Up To 150 Notes, Four Ways
- Operating Temperature: 0°C To 60°C
- Storage Temperature: -40°C To 70°C
- Operating Humidity: 15% To 95% Relative Humidity
- Firmware Updates: Remote Software Updates For Firmware And Note Sets
- Acceptance Rate: 98% Or Higher
- Power Requirements: 24VDC (-10% / +20%)
- Current Consumption:
- Standby: 0.5A
- Accepting: 8A
- Validation Sensors: Optical Sensors
Technical Specifications
| Brand | Crane MEI |
| Voltage | 24v |
| Stacker Capacity | 600 Bills |
| Condition | New |
