Description
The MEI SCN8347N EDBS/SPC SC Advance Note Validator is a high-performance banknote validator featuring EDBS/SPC communication compatibility, No Cashbox (Stackerless) configuration, advanced note recognition technology, and barcode ticket acceptance. Designed for gaming, kiosk, retail, and unattended payment applications, it delivers reliable note validation, enhanced security, and flexible cash management integration.
Key Features
- Genuine MEI SC Advance™ Note Validator
- SCN8347N EDBS/SPC Configuration
- EDBS/SPC Communication Support
- No Cashbox (Stackerless) Design
- Packaged Unit Configuration
- Advanced Note Recognition Technology
- High First-Pass Acceptance Rate
- Supports Over 140 Global Currencies
- Barcode Ticket Acceptance
- Four-Way Bill Insertion
- Full Spectral Note Validation
- Advanced Anti-Fraud Protection
- Sealed Note Path Design
- Anti-Skew Transport Technology
- Fast Note Processing
- Durable Industrial Construction
- Easy Firmware Updates
- Low Maintenance Requirements
- High Reliability Performance
- OEM Factory Configuration
- Product Type: Banknote Validator
- Series: SC Advance™
- Model: SCN8347N EDBS/SPC
- Configuration: SCN83
- Communication Interface: EDBS/SPC
- Cashbox: None (Stackerless Version)
- Package Type: Packaged Unit
- Acceptance Rate: 98% Or Greater
- Currency Support: Over 140 Global Currencies
- Note Insertion: Four-Way Acceptance
- Note Width Range: 62 mm – 83 mm
- Note Length Range: 120 mm – 166 mm
- Escrow Capacity: One Note Or One Barcode Coupon
- Processing Speed: Approximately 2.3 Seconds
- Operating Temperature: 0°C To 60°C
- Storage Temperature: -30°C To 70°C
- Humidity Range: 5% To 95% Non-Condensing
- Input Voltage: 12V – 28VDC
- Standby Power Consumption: 10 Watts
- Accepting Power Consumption: 30 Watts
- Peak Power Consumption: 70 Watts
Technical Specifications
| Brand | Crane MEI |
| MPN | 252006166P1 |
| Voltage | 12V – 28VDC |
| Condition | New |
