Description
Overview
The MEI Talos T602-U7EUS is a U.S.-currency MDB bill validator, equipped with a 12-pulse (parallel) interface harness, from the Crane MEI Talos T6 Series, designed as the direct replacement for the AE2602-U7EUS. It delivers faster note validation, improved optical accuracy, and modular servicing through Crane’s next-generation Talos platform.
Built with a rugged VFM front-mount bezel and a 700-note Up-Stacker, this model runs on 24 V DC / 34 V DC MDB power. It’s ideal for vending, kiosk, and amusement systems where reliability, speed, and serviceability are essential.
Key Features
- Accepts U.S. $1–$20 bills with 4-way optical validation
- Standard MDB interface with a 12-pulse (parallel) interface harness for vending, kiosk, and amusement systems
- Replaces legacy AE2602-U7EUS
- VFM Bezel — standard front-mount design for vending and amusement machines
- Up-Stacker with 700-note cassette capacity
- Advanced anti-counterfeit and anti-stringing protection
- Upgradeable firmware via USB or handheld programmer
- Quick-release stacker for tool-free maintenance
Technical Specifications
| Currency | U.S. Dollar (USD) |
|---|---|
| Interface | MDB Protocol |
| Bezel Type | VFM Front-Mount Bezel |
| Stacker Orientation | Upward (Up-Stacker) |
| Operating Voltage | 24 V DC / 34 V DC |
| Stacker Capacity | 700 notes (interchangeable cassette) |
| Bill Insertion | 4-way acceptance (any orientation) |
| Operating Temperature | 0 °C – 50 °C (32 °F – 122 °F) |
Model Breakdown
| Code | Meaning | Description |
|---|---|---|
| T | Series | Talos Series — Crane MEI’s modern bill validator platform with modular design and high-speed optics. |
| 6 | Model Family | T6 Series — direct replacement for AE26xx validators. |
| 0 | Bezel Type | VFM Bezel — standard front-mount for vending and amusement machines. |
| 2 | Power Configuration | 24 V DC / 34 V DC MDB operation. |
| U7 | Stacker / Capacity | Up-Stacker with 700-note cassette capacity. |
| EUS | Build Code | U.S. standard MDB build (E-series mainboard) with a 12-pulse (parallel) interface harness. |
Summary:
The MEI Talos T602-U7EUS replaces the AE2602-U7EUS, featuring a VFM front-mount bezel, Up-Stacker design, 700-note cassette, and 24 V DC MDB operation for vending and amusement systems.
BillAcceptors.us is an authorized Crane MEI distributor with over 30 years of experience, offering the best prices and repair support.
Technical Specifications
| Brand | Crane MEI |
| Voltage | 34v |
| Supported Protocols | MDB |
| Stacker Capacity | 700 Bills |
| Bezel Type | MEI VFM Upstacker "0" |
| Denomination Acceptance | $1-$20 |
| Condition | New |
