Description
Overview
The MEI Talos T611-U7EUS is a U.S.-currency 110 V AC bill validator from the Crane MEI Talos T6 Series, engineered as the direct replacement for the AE2611-U7EUS. It delivers improved note acceptance speed, enhanced optical accuracy, and a modular frame for quick service and maintenance in legacy 110 V systems.
Equipped with a VFM front-mount bezel and a 700-note Up-Stacker, this model runs on 110 V AC power. It’s ideal for vending, kiosk, and amusement applications that still require AC-powered interfaces but demand modern Crane Talos reliability.
Key Features
- Accepts U.S. $1–$20 bills with 4-way optical validation
- 110 V AC pulse / parallel interface for legacy systems
- Replaces legacy AE2611-U7EUS
- VFM Bezel — standard front-mount design for vending and amusement machines
- Up-Stacker with 700-note cassette capacity
- Advanced anti-counterfeit and anti-stringing protection
- Upgradeable firmware via USB or handheld programmer
- Quick-release stacker for tool-free maintenance
Technical Specifications
| Currency | U.S. Dollar (USD) |
|---|---|
| Interface | 110 V AC Pulse / Parallel / Legacy |
| Bezel Type | VFM Front-Mount Bezel |
| Stacker Orientation | Upward (Up-Stacker) |
| Operating Voltage | 110 V AC ± 10 % |
| Stacker Capacity | 700 notes (interchangeable cassette) |
| Bill Insertion | 4-way acceptance (any orientation) |
| Operating Temperature | 0 °C – 50 °C (32 °F – 122 °F) |
Model Breakdown
| Code | Meaning | Description |
|---|---|---|
| T | Series | Talos Series — Crane MEI’s advanced validator platform with optical security and modular design. |
| 6 | Model Family | T6 Series — direct replacement for AE26xx validators. |
| 1 | Bezel Type | VFM Compact Front-Mount Bezel for vending and amusement applications. |
| 1 | Power Configuration | 110 V AC input for legacy non-MDB systems. |
| U7 | Stacker / Capacity | Up-Stacker with 700-note cassette capacity. |
| EUS | Build Code | U.S. E-series mainboard configuration with Talos firmware. |
Summary:
The MEI Talos T611-U7EUS replaces the AE2611-U7EUS, featuring a VFM Compact Bezel, Up-Stacker design, 700-note cassette, and 110 V AC operation for legacy vending and amusement systems.
BillAcceptors.us is an authorized Crane MEI distributor with over 30 years of experience, offering the best prices and repair support.
Technical Specifications
| Brand | Crane MEI |
| Voltage | 110v |
| Supported Protocols | Pulse, Serial |
| Stacker Capacity | 700 Bills |
| Bezel Type | MEI Compact Upstacker "1" |
| Denomination Acceptance | $1-$20 |
| Condition | New |
