Description
The ICT A6E-13NCP-USD4 Bill Validator (A6E Series) is built for secure and efficient banknote validation in vending and automated payment systems.
This model operates on 110V AC power and supports the Pulse (STD Pulse) interface, ensuring compatibility with a wide range of machines.
It features a 300-note stacker capacity and is equipped with a downstack bezel, supporting smooth vertical bill insertion and stacking. This version includes a cover mounting kit for easier installation into compatible equipment.
High acceptance accuracy (96% or higher), fast processing (~3 seconds), and reliable operation .
Key Features
- Pulse interface (STD Pulse)
- 110V AC operation
- 300 note stacker
- Downstack bezel configuration
- Cover mounting kit included
- Four-way bill insertion
- Auto-calibration
- Easy installation and maintenance
- Series: ICT A6E Series
- Interface / Protocol: Pulse (STD Pulse)
- Power Supply: 110V AC
- Stacker Capacity: 300 notes
- Bill Insertion: Four-way
- Acceptance Rate: 96% or higher
- Transaction Time: Approx. 3 seconds
- Bill Width Accepted: 60–67 mm
- Operating Temperature: 0°C to 55°C
- Humidity: 30%–85% RH (non-condensing)
Technical Specifications
| Brand | ICT |
| Voltage | 110v |
| Supported Protocols | Pulse |
| Stacker Capacity | 300 Bills |
| Bezel Type | Downstacker |
| Denomination Acceptance | $1-$20 |
| Condition | New |
